Overview of Advantages
◇Drop-down seal for metal, wood and PVC doors
◇Drop height up to 16 mm
◇Sound absorption level up to 50 dB with optimal sealing
◇Unilateral and silent actuation
◇No scraping / trailing on the floor, thanks to parallel drop
◇Automatic compensation of sloped floors
◇For double-leaf doors with flush bolt or shoot bolt
◇High-quality silicone lip, lateral protrusion adjustable
◇Easy drop height adjustment
◇Can be shortened to the next smaller stock length
| Groove size | 20,3 mm wide and 20,5 to 25 mm deep |
| Seal profile | high-quality silicone or high-quality self-extinguishing silicone |
| Sound absorption value | up to 50 dB at ground air 7 mm |
| Fastening | with stainless steel mounting bracket and self-tapping screws on the side |
| Can be shortened | max. 125 mm (335 mm only 115 mm) |
| Release | on one side, hinge side |
| Drop height adjustment | on release pin with 3 mm Allen key |
| Max. drop height | 16 mm |
| Profile size | 19.8 x 20 mm |
| Profile material | aluminium |
| Version | fire-retardant smoke-shielding |
| Length | 1460 mm |
| can be shortened to | >1335 mm |
